Overview
Rugged AI PC
Equipped with the Intel® Core™ Ultra processor and Arc™ integrated graphics, this rugged AI PC delivers exceptional performance with a dedicated NPU for enhanced AI computing. The Windows 11 OS, combined with dual memory and storage slots, ensures smooth multitasking and expandable productivity. A 14-inch fully laminated display with optional glove touch is built for versatility, meeting IP65 and MIL-STD-810H standards for durability in tough conditions. The Thunderbolt 4 interface supports high-speed data transfers and seamless connectivity with multiple devices. Powered by a dual-battery system (56Wh + 14.4Wh), including a removable option, it offers extended operation for demanding tasks. Designed for global industries, this rugged AI PC is the ultimate tool for challenging environments.
Intel Core Ultra Processor
The Intel® Core™ Ultra processor With a dedicated AI engine (NPU) Delivering efficient AI power
Intel® Arc™ Graphics
Intel® Arc™ integrated graphics With Xe LPG architecture Dedicated-level performance
Windows + AI
Windows 11 OS Dual Memory/Dual Storage Slots Unleash seamless productivity
Thunderbolt 4 Interface
High-speed Thunderbolt 4 interface HDMI 2.0, USB, RJ45, RS232,etc. Seamless integration of multiple devices
High-Capacity Dual-Battery
56Wh + 14.4Wh dual battery Large battery is removable Switchable Modes for Versatility
Durable Body For All-Scenario Use
he 14-inch fully laminated display Supports optional 10-point touch and glove touch IP65 & MIL-STD-810H Certified
363.2*287.4*42.1mm
TBD
Black
Type: FHD
Resolution: 1920*1080
Brightness: 1000cd/㎡
Size: 14-inch 16:9
Optional 10-Point Capacitive Screen, G+G, Corning Gorilla Glass; Hardness above 7H; Scratch-resistant; Supports glove touch
USB3.2 *1, USB3.0 *1, USB2.0 *1
TYPE-C
∮3.5mm Standard Earphone Jack *1
RJ45 *2 (10M/100M/1000M adaptive)
RS232 *1
HDMI *1
12PIN Pogo Pin
DC19V/3.78A ∮5.5mm power interface *1
Optional
US Layout Keyboard with Backlight
Intel® Core™ Ultra
Windows 11 PRO
RAM：16GB
ROM：256GB SSD
DC input 100-240VAC0.5A50/60Hz DC19V/3.78A 71.82W American Standard Optional: European Standard
Front 5.0MP
1300mah/11.1V (14.4WH)
4850mah/11.55V（56WH）
Built in, ×1 SPI Fingerprint (Power-On Login)
WIFI6
2G/3G/4G
5G Optional M.2
BT5.1
Supports single GPS or single Glonass, default GPS
IP65
CE, UN3803, Optional FCC, CCC
MIL-STD-810H
MIL-STD-810H: 1.22m drop resistance
Working temperature: -20 °C to 60 °C
Storage temperature: -30 °C to 70 °C
Humidity: 95% Non-Condensing
DC19V/3.78A adapter
Removable Battery
MDC14 Battery Quad-charging Dock
